X7 CCTV & Sonar Pipe Inspection
Prix : 1000USD-40000USD
The CCTV detection sonar floating system adopts sonar imaging technology and CCTV video detection technology. The underwater scanning unit (sonar head) and the water detection unit (rotating lens) are placed on the water surface inside the pipeline (full pipe or half pipe). Using crawler or manual drag method to drive (glide, float) to move in the pipeline. You can use a personal laptop or special controller to control our pipe CCTV camera.
X7 CCTV & Sonar Pipe Inspection Main Parts
Sonar Probe
Size: total length: 485mm, diameter: 70mm;
Material: aluminum alloy shell;
Waterproof: IP68;
Operating temperature: 0~40℃;
Storage temperature: -20~70℃;
Weight in air: 2.7kg;
Acoustic frequency: 1MHz;
Beam width:1.1deg (-3db), conical beam;
Range resolution (0.125m range) : 0.5mm;
Maximum applicable pipe diameter: 6000mm;
Transmitting pulse width:4~20us;
Receiving bandwidth:500KHz;
Power supply: 48V dc;
HD P&T Camera
IP68 up to 10m water depth
Working ambient temperature: -10℃~50℃
Light source: 4x 3W LED light
The radial rotation 360°,horizontal rotation ±135°,one click to reset
10X optical, 12X digital
Laser measurement for crack
Lens: color 1/3”, 2592*1520, CMOS, viewing angle 6.7°-68°,sensitive 0.1 lux, auto-focusing
Dimension( LxWxH): 155x95x90mm
Weight: about 1.5kg
Cable Reel
Cable length: 150m
Motor-driven
2-pin cable, drawing anti-Kevlar 300 kg, imported polyurethane sheath, cable diameter <6mm, waterproof, wear, acid, corrosion.</span>
Cable retracting automatically or manually
Accurate cable counter, devition within 1mm
Compatible with Easy-Sight X5-H series crawlers and X4 sonar pipeline inspection system
Protection class: IP63
Dimension( LxWxH): 570x395x475mm
Weight: about 45 kg( with 150m cable)
Main Controller
Regular computers or tablets can be used as the main controller with build-in inspection collection software. Both the main controller and joystick can control the cctv camera inspection of to go forward, back, and turn. The main controller can also control camera rotating, light and so on. Equipped with sewer pipe cctv inspection and evaluation report software and onar pipeline sonar imaging analysis report software. The former is used to control and operate the robot, video surveillance and recording, fill in inspection records on site and take screenshots for interpretation; the latter is used to display and collect inspection images in real time during the inspection process, and can perform contour extraction, interpretation analysis, 3D reconstruction and report output .
Floating Boat
UPVC material, suitable pipe width:DN500mm~6000mm;
Size: 870mm * 458mm * 300mm;
Weight: 8kg;
Flotage: 15kg;
As one of cctv drain camera suppliers, we can offer sorts of drainage cctv equipment for sale, if you have needs to buy cctv drain camera, please contact us.
More professional intelligent pipeline solution, please visit our website.
