Veterinary Handheld Ultrasound Scanner
Quantité : 1 piece Prix : N/A
Product Description
3.5MHz Convex probe (2.5-3.5-5.0 MHz) |
application: medium animals such as pigs, sheep, big dogs and etc |
||||
5.0MHz Micro-ConvexProbe (4.5-5.0-5.5 MHz) |
application: small animals such as pigs, sheep, canines, fox and vets. |
||||
6.5 MHz Rectal Probe (5.5-6.5-7.5 MHz) |
application: big animals such as cows, horses, camel, hippo and etc. |
||||
7.5 MHz Linear Probe (6.5-7.5-8.5 MHz) |
application: little small animals (weight≤5 kilogram) such as cats, dogs, rabbits, snakes, fish and etc. |
||||
Brief introduction: |
This ultrasound machine for dog breeders is high resolution linear/convex ultrasound scanning diagnostic equipment. It adopts micro-computer control and digital scan converter (DSC), digital beam-forming (DBF), real time dynamic aperture (RDA), real time dynamic receiving apodization, real time Dynamic receiving focusing (DRF), Digital frequency Scan (DFS), frame correlation technologies to endue its image with clarity, stability and high resolution. |
||||
Standard Configuration: |
-Main unit(containing a piece of Li-ion battery) -3.5MHz Convex probe -Wrap bag -Manual/ technical instructions -Main charger (AC-adapter) -Outside protective box ( as packing details show) |
||||
Optional: |
-5.0MHzmicro-convex probe -6.5MHz rectal probe -7.5MHz linear probe -Video printer -Li-ion battery -Car charger -Charging adaptation wire(containing power cord) |
||||
Specifications: |
Probe |
L1-5/7.5Mhz linear probe;6.5Mhz rectal probe |
C1-11/50R/3.5Mhz convex probe |
C1-12/20R/5.0Mhz micro-convex probe |
|
Detect Depth(mm) |
≥80 |
≥140 |
≥90 |
||
Resolution/mm |
Lateral |
≤1 (depth≤60) |
≤3 (depth≤80), ≤5 (80 < depth≤130) |
≤3 (depth≤60) |
|
Axial |
≤1 (depth≤80) |
≤1 (depth≤80) |
≤1 (depth≤60) |
||
Blind zone(mm) |
≤3 |
≤6 |
≤5 |
||
Geometric position precision |
Horizontal |
≤5 |
≤7.5 |
≤7.5 |
|
Vertical |
≤5 |
≤5 |
≤5 |
||
Monitor size |
5 inch |
||||
Display mode |
B, B+B, B+M, M, 4B |
||||
Image gray scale |
256 |
||||
Image storage |
128 |
||||
Cine loop |
≥400 frame |
||||
Scan depth |
120mm-220mm |
||||
Image flip |
Up/down, left/right |
||||
Focus position |
Adjustable |
||||
Posture mark |
15 |
||||
Image process |
Histogram, color encode, gama, image smooth |
||||
Probe frequency |
Adjustable ( 3 point each probe ) |
||||
Frame correction |
Adjustable |
||||
Measurement |
Distance, circumference, heart rate, EDD, area, volume, GA, |
||||
Notation |
Date, time, name, , age, full screen words edit and etc. |
||||
Output report |
Regular |
||||
Output |
USB2.0, VIDEO( PALD, NTSC) |
||||
Battery continuous work |
≥3 hours |
||||
Machine size |
230mm(L)x120mm(W)x38mm(H) |
||||
Net weight |
700g |
BATERSUARG has an independent product R&D center, technical service and training center, production, sales, and operation center in China, and has built a professional animal breeding and diagnostic sales service system covering the whole world. And we provide veterinary ultrasound scanner for sale.
