TJH-1B Weighing Load Cell
High precision, easy installation, good moisture resistance, suitable for electronic belt scales, packaging scales, etc.
Specifications of TJH-1B load cell for weighing machine
|
Technical Parameter |
|
|
Rated Load |
1~1.5 kN |
|
Comprehensive Precision |
0.05% FS |
|
Sensitivity |
1.5,2.0 mV/V |
|
Creep |
±0.05% FS/30min |
|
Zero Output |
±1% FS |
|
Temperature Effect On Zero |
±0.05% FS/10℃ |
|
Temperature Effect On Output |
±0.05% FS/10℃ |
|
Operating Temperature Range |
-20~+65 ℃ |
|
Input Resistance |
680±15 Ω |
|
Output Resistance |
650± 5 Ω |
|
Insulation Resistance |
＞5000 MΩ |
|
Safe Load Limit |
150% FS |
|
Bridge Voltage |
Reference 10V DC |
|
Material |
Alloy Steel |
|
Load Cell Mode Of Connection |
Input+: Red |
|
Input-: Black |
|
|
Output+: Green |
|
|
Output-: White |
|
As one of the most professional tension load cell manufacturers, Tianguang Sensor provides load cell weighing scale, weighing scale sensor, force transducers, load cells for sale and etc. Contact us to know weighing scale load cell price or type of load cell.
