Tight Buffer FBG Array
FBG is a core element used as a sensor for structure health monitoring. The tight buffer FBG array consists of FBG array sensors. The outer layer could be material of PVC, nylon or hytrel which protects the FBG sensors and ruggedizes the construction.
The fiber optic buffer array is designed to make handling and installation fast, easy and intuitive. It delivers the many advantages inherent to all FBG based sensors while elevating the degree of ruggedness to be consistent with, if not exceeding, industry expectations.
Features Of Tight Buffer FBG Array
High Sensitivity Ribbon
Increased Bonding Strength
Embeddable Ribbon Sensor
Surface Mount Ribbon Sensor
Easy Handling and Deployment
Low Cost and Long Lifetime
Application Of Tight Buffer FBG Array
Perimeter Monitoring
Building Security
Energy
Civil Engineering
Specifications Of Tight Buffer FBG Array
Parameters |
Unit |
Values |
Center Wavelength |
nm |
1460 ~ 1610 |
Wavelength Tolerance |
nm |
+/-0.5 |
FBG Length |
mm |
5~10 |
Reflectivity |
% |
>70 |
Reflection FWHM |
nm |
<0.3</span> |
SLSR |
dB |
≥15 |
Strain Sensing Sensitivity |
pm/με |
1.2 |
Sensor Strength |
KPSI |
>150 |
Temperature Calibration Constant for -20C to 120C |
pm/°C |
~20 |
Optical connector |
-- |
FC/UPC, FC/APC Or E2000 |
AtGrating is a professional supplier for optical fiber sensing. AtGrating offers fiber optic sensor, fiber bragg grating pressure sensor, tight buffer fiber, tight buffered fiber cable, buffered fiber, tight buffered fiber optic cable, tight buffer cable, tight buffered, fiber sensing, etc. For more information, please feel free to contact us!
