Sell DX-130 Digital Gauss Meter, Tesla Meter

Quantité : 1 set   Prix : USD700.00/SET, EXW X

DX-130 Full-digital Gauss Meter

DX-130 Full-Digital Gauss/Tesla Meteris designed for applications requiring high precision, high-resolution magnetic field measurement. It is an intelligent solutions against the traditional Analog, digital table header type Gauss / Tesla meter.It is a high precision intelligent apparatus, which integrates measuring, storage, industrial control, communication just in one machine. DX-130 takes advantage of microprocessor technology to provide you with high-precision, higher refresh rate and display resolution and high measurement repeatability and stability in your research and production. With simple and convenient operation panel and the full menu, 4 ¾-bit resolution readings, a high-resolution 1 / 60000, so that you can view 1Gs weak changes in the high magnetic field measurements. It has a maximum range up to 30KG (3T). It has a large capacity of data storage and you can review data according to storage time. It is suitable for a full range of DC magnetic field measurement.It is mainly sold to research institutes and various types of production units.

Features

4 ¾-bit resolution on wide-screen LCD panel

Auto-zero, automatic/manual range

Maximum/minimum/peak/valley holding and interface locking

RS-232C interface

Display units optional Gauss or Tesla

Threshold setting and alarming

Probe Auto Calibration

Optional dozens of kinds of basic or custom probe

Communication baud rate adjustment

Standard 1.00mm ultra-thin consistency probe

Data-storage(auto/manual)/historical-data reviewing

Time set /working temperature display

Optional: Remote Control System, Gauss Meter Professional mapping software, Industrial control output components, zero gauss chamber

Specification



1mT = 10Gs

Range

1Gs-300KGs

Resolution

1Gs(0.1mT)

Accuracy (display value)

DC

Reading of± 0.50% ± 0.05% range

Frequency range

DC mode

DC

Display Panel

Wide-screen LCD

Additional effects

Temperature Coefficient

±(0.03% ±1 count)/ ºC

Temperature range

Working temperature

0ºC to +50ºC

Storage temperature

-10ºC to +60ºC

Panel Display

128*64 LCD

Communication Interface

RS-232 Standard 9-pin D-type connectors

Supply power

Voltage: 200/240v Frequency: 50-60 Hz

Using occasions

Permanent magnet material surface magnetic field, DC motors, speakers, magnetic separator, and permanent magnetic separator magnetic field of work. Magnetic circuit gap and slit field within the magnetic field. Also it can apply to the detection machining residual magnetic field after the goods, distribution of magnetic field, the remaining magnetic after demagnetization, the magnetic of motor and magnetic flux leakage of electromagnetic fields and other kinds of magnetic field intensity of magnetic induction.Industrial interface can be installed if needed.
