Sell DX-130 Digital Gauss Meter, Tesla Meter
Quantité : 1 set Prix : USD700.00/SET, EXW X
DX-130 Full-digital Gauss Meter
DX-130 Full-Digital Gauss/Tesla Meteris designed for applications requiring high precision, high-resolution magnetic field measurement. It is an intelligent solutions against the traditional Analog, digital table header type Gauss / Tesla meter.It is a high precision intelligent apparatus, which integrates measuring, storage, industrial control, communication just in one machine. DX-130 takes advantage of microprocessor technology to provide you with high-precision, higher refresh rate and display resolution and high measurement repeatability and stability in your research and production. With simple and convenient operation panel and the full menu, 4 ¾-bit resolution readings, a high-resolution 1 / 60000, so that you can view 1Gs weak changes in the high magnetic field measurements. It has a maximum range up to 30KG (3T). It has a large capacity of data storage and you can review data according to storage time. It is suitable for a full range of DC magnetic field measurement.It is mainly sold to research institutes and various types of production units.
Features
4 ¾-bit resolution on wide-screen LCD panel |
Auto-zero, automatic/manual range |
Maximum/minimum/peak/valley holding and interface locking |
RS-232C interface |
Display units optional Gauss or Tesla |
Threshold setting and alarming |
Probe Auto Calibration |
Optional dozens of kinds of basic or custom probe |
Communication baud rate adjustment |
Standard 1.00mm ultra-thin consistency probe |
Data-storage(auto/manual)/historical-data reviewing |
Time set /working temperature display |
Optional: Remote Control System, Gauss Meter Professional mapping software, Industrial control output components, zero gauss chamber
Specification
|
1mT = 10Gs |
|
Range |
1Gs-300KGs |
|
Resolution |
1Gs(0.1mT) |
|
Accuracy (display value) |
DC |
Reading of± 0.50% ± 0.05% range |
Frequency range |
DC mode |
DC |
Display Panel |
Wide-screen LCD |
|
Additional effects |
Temperature Coefficient |
±(0.03% ±1 count)/ ºC |
Temperature range |
Working temperature |
0ºC to +50ºC |
Storage temperature |
-10ºC to +60ºC |
|
Panel Display |
128*64 LCD |
|
Communication Interface |
RS-232 Standard 9-pin D-type connectors |
|
Supply power |
Voltage: 200/240v Frequency: 50-60 Hz |
Using occasions
Permanent magnet material surface magnetic field, DC motors, speakers, magnetic separator, and permanent magnetic separator magnetic field of work. Magnetic circuit gap and slit field within the magnetic field. Also it can apply to the detection machining residual magnetic field after the goods, distribution of magnetic field, the remaining magnetic after demagnetization, the magnetic of motor and magnetic flux leakage of electromagnetic fields and other kinds of magnetic field intensity of magnetic induction.Industrial interface can be installed if needed.
Personne à contacter : Lisa Cao, 086 592 5558386
