QSFP 100G 1310nm 10km LC Transceiver

QSFP 100G 1310nm 10km LC Transceiver(100g lr4) product is a 100Gb/s transceiver module designed for optical communication applications compliant to 100GBASE-LR4 of the IEEE P802.3ba standard. The module converts 4 input channels of 25Gb/s electrical data to 4 channels of LAN WDM optical signals and then multiplexes them into a single channel for 100Gb/s optical transmission. Reversely on the receiver side, the module de-multiplexes a 100Gb/s optical input into 4 channels of LAN WDM optical signals and then converts them to 4 output channels of electrical data.

The central wavelengths of the 4 LAN WDM channels are 1295.56, 1300.05, 1304.58, and 1309.14 nm as members of the LAN WDM wavelength grid defined in IEEE 802.3ba. The high-performance cooled LAN WDM EA-DFB transmitters and high sensitivity PIN receivers provide superior performance for 100Gigabit Ethernet applications up to 10km links and are compliant to optical interface with IEEE802.3ba Clause 88 100GBASE-LR4 requirements.

The 100g qsfp28 transceiver is designed with form factor, optical/electrical connection, and digital diagnostic interface according to the QSFP+ Multi-Source Agreement (MSA). It has been designed to meet the harshest external operating conditions including temperature, humidity, and EMI interference.

Technical Specification Of QSFP 100G 1310nm 10km LC Transceiver

Absolute Maximum Ratings

QSFP-100G-LR4 has to be noted that the operation in excess of any individual absolute maximum ratings might cause permanent damage to this module.

We are committed to providing satisfactory products, solutions, and services to customers. As one of the most professional fiber transceiver manufacturers, we provide 100G-QSFP28-LR4-10KM, lr4 100g, qsfp28 lr, single mode transceiver over multimode fiber, 100ge lr4, 100g lr4 optics,DAC cable and etc. Contact us to know qsfp 100g lr4 s price / qsfp28 lr4 price.
