Photovoltaic 1000 DC Power SPD
SPD for DC power, SPD 1000VDC; In(8/20us): 20kA/phase, Imax: 40kA/phase; hot-pluggable; fault indication;
Features & Advantages of Photovoltaic DC SPD 1000
Status indication:
Green: OK
Red: Failed
DC power surge protector modules can be replaced online.
Remote alarm output is optional, named with "F".
It is normally installed at the boundary of LPZ1 and LPZ2 or subsequent LPZs.
Parameter of 1000 DC Power Photovoltaic SPD
|
|
T2-1000 |
|
Max. continuous operating voltage Ucpv |
1000VDC |
|
Short-circuit current rating Iscpv |
1000A |
|
Nominal discharge current In(8/20µs) |
20kA |
|
Max. discharge current Imax(8/20µs) |
40kA |
|
Voltage protection level Up |
4kV |
|
Recommended backup fuse |
80A gG |
|
Recommended grounding cable |
6~35mm2 |
|
Response time |
25ns |
|
Residual current IPE |
<10μA</span> |
|
Remote alarm output |
250VAC/0.5A;24VDC/0.5A |
|
Housing protection grade(IEC60529) |
IP 20 |
|
Housing material/inflammability rating(UL94) |
PA66/V0 |
|
Testing standard |
IEC 61643-31 |
CHENZHU strives to provide high-quality products and services to meet the expectations of our customers and interested parties by delivering outstanding performance. We have special talents to research and develop safety and automation system. Indeed, automation and safety are our interface products' main characters.
