M10 Solar Cell
M10 solar cell, compared with the existing product span, equipment, process, auxiliary material maturity, production line upgrading difficulty, current product yield, and other factors, the M10 cell busbar P-type bifacial half-cut is the best size to achieve ultra-high power modules, more mature industrial ecology, fewer transportation problems.
Higher Generation Process Of The Modules
The M10 cell P-type bificial half cut solar cell could provide up to 30% of the gain in the generation process of the modules, as for the half cut cell technology has a higher conversion efficiency than the full piece.
Lower Rated Operating Temperature
Compared with the full cell modules, the temperature of the mono perc cell module is 2-3 degrees lower, and the hot spot temperature is 10-20 degrees lower.
Lower Shadow Shielding Loss
Solar cell M10 module has a lower shadow shielding loss.
Types Of The M10 Solar Cells For Sale
M10 Cell 182-91mm 10BB Mono P-type Bifacial Half Cell
Dimension: |
182mm×182mm±1.5mm,Diagonal 247mm±0.5mm |
Thickness (Cell): |
180±18μm |
Front (−): |
10*0.06mm+-0.03mm main busbar(silver)136+-10mm asitbusbar, Blue anti-reflecting coating (silicon nitride) |
Back (+): |
width of back electrode(silver) 1.4±0.3mm, finger grids(aluminum), dotted laser design |
M10 Cell 182-91mm 11BB Mono P-type Bifacial Half Cell
Dimension |
182mm×182mm±1.5mm |
Thickness (Cell) |
180±18μm |
Front (−) |
1.0mm/1.5mm wide soldering pads(silver) and 0.1mm bus bars(silver), SiOx/SiNx stack |
Back (+) |
1.3mm wide soldering pads(silver), AlOx/SiNx stack layers (PERC structure) |
Applications of the M10 Solar Cells
Sunrise M10 cell is mainly used for Aquaman series solar modules. It supports single-sided, double-sided, and all-black customization requirements. The size can be provided according to the installation scene, such as 108 cells, 120 cells, 144 cells, 156 cells, etc. After high-precision packaging The maximum module power is 595w.In distributed photovoltaic systems, medium and large ground power stations have mature applications. Compared with conventional modules, M10 solar cells are the optimal size to match the market.
For more information about half cut solar panel vs full cell and buy sunrise panels, please feel free to contact us!
There are many solar products suppliers, but we are one of the best choices for you.
