Specifications

Warranty: one year

Fuel: anthracite,coke

Calorific Value: 5000-6500kcal/Kg

Activity degree: ≥280ml,Up to 350ml

Packaging & Delivery

Packaging Details: Standard Export Package

Delivery Detail: 30 days against down payment

Product Description

Vertical Lime Kiln is building material equipment, is the main equipment for sintering cement clinker in cement production plant, which can be divided into cement kiln, metallurgy chemical kiln and lime kiln according to different materials .

Vertical Lime Kiln is used in the most important equipment in lime production line.

Detailed Parameters

Kiln total height: 32—52.8M (according to the output)

Kiln effective height: 16.5—34.5M (according to the output)

Kiln outer diameter: 3.6—7.5M (according to the output)

Kiln inner diameter: 2.4—5.3M (according to the output)

Structure: Steel structure outside and firebrick build inside

Area: 2000—4000m2

Output capacity: 50—400tons

Kiln volume: 75-750m³

Limestone particle size: 40—80mm

Limestone calcine temperature: 900—1200°C

Lime discharging temperature: 40—80°C

Lime calcine cycle: Circulating

Availability of lime: 280—320ml

Calcium oxide contents: 80—95%

Defective lime rate: <10%</p>

Fuel: anthracite,coke

coal consumption: 130kg standard coal per ton lime

Control system: PLC control

Monitor system: 24 hours monitor

Operators: Two kilns one group, each group three operators

High temperature pocket type dust removing rate: 99%

Desulphurization rate: 95%

Environmental standard: National secondary standard

Draft fan wind pressure/wind volume: 300pa/3500m³/h

Forced fan wind pressure/wind volume: 4000pa/30000m³/h

Wind blow type: Ring shaped machinery continuous fan

Lime discharging type: All sides discharge

Power: 135—283.5Kw

Construction period: 100—120 working days

Advantages

1. International High Quality Certification :

To open the globle market ,we have passed the ISO 9001 ,ISO 50430 ,ISO14000 ,BV certification ,quality guarantee .

2. Manufacture .

OEM service ,QC system with more resonable price .

3. Experienced Techncians .

With over 20 years' practical experience ,our engineers and workers can skillfully complete the process.

4.Competitive Price

Payment terms can be negotiated ,more reasonable price under the same quality.
