Specifications

Condition: New

Place of Origin: Henan, China (Mainland)

Voltage: 380V/50HZ or customed

Power(W): 3-110kw

Weight: depend on the detail model

Certification: CE, ISO,CCC,BV

Warranty: one year

Material: Q345 Aolly steel

Drying temperature: ≤750℃

Kaolin Iput Moisture: 30%-50%

Kaolin output moisture: 10%-12%

Rotary Kiln Nickel Ore Dryer

1.Special Lifting Device

2. High efficient, saving energy

3. coal, oil, gas as fue

Packaging & Delivery

Packaging Details: Rotary Drum Dryer Loading with 20GP,40GP,40HQ container, main frame nude packing, motors and other parts is wooden box package.

Delivery Detail: Rotary Dryer Machine delivery 15 days after received payment

Rotary Kiln Nickel Ore Dryer Introduce

The dryer machine are used for drying the high moisture material to a suitable moisture, so that the material can be reached a high efficient use value.

Application of Rotary Kiln Nickel Ore Dryer:

The dryer is widely used in the field of building materials, metallurgies, chemical industry, cement,biomass and so on.

It can dry slag, coal powder, mining powder, clay, sand, limestone,solid dryer, palm fiber, manure, slurry, manganese ore,sawdust, wood chips, wood shaving and so on. It is made into rotary body, lifting blade, driving device, supporting device etc.

We supply the following dryer:

high moisture wet material rotary dryer, sand dryer, sawdust dryer, coal dryer, coal slime dryer, bentonite dryer, ore concentrate dryer, wood chip dryer, cassava dryer, gypsum dryer, cow dung dryer.

The heating source of Rotary Kiln Nickel Ore Dryer:

You can use coal, natural gas, electricity, oil,biomasss,LPG and wind power to heat the dryer machine.

Generally Speaking, the choice of fuel is based on the local suitable heating source,so as to achieve the heating source comprehensive utilization.Also,the cost of the dryer can be reduced with local highly cost effective heating source.

What the component of Rotary Kiln Nickel Ore Dryer:

1.the tube body

2. roller circle pam

3.roller

4.package hoop

5.motor

6.coupler

7.reducer

8.small gear

9.bearing box

10.spring plate

11.big gear

12.drive axis

13.roller axis

14.carrier roller

15.bearing

16.roller base

17.transmission base 1

8.guiding plates

19.lifting plates

How to work of Rotary Kiln Nickel Ore Dryer:

1. First, materil after transfer system enter into the rotary drum dryer cylinder, flied by raising plate device which are uniform distribution in the drum cylinder.

2. The material are evenly distributed in rotary drum dryer cylinder which can bear high temperature, then fully contact with the hot air, speed up the drying heat and mass transfer.

3. During the drying process, under the effect of plate and hot treatment in the rotary drum dryer, the materials are dryed well.

4. At last, the dried material come out from the end of the rotary drum dryer.

The Rotary Kiln Nickel Ore Dryer characteristics:

1.Our Rotary Drum Dryer have CE certificater. The parts of the machine we all use nation standard.

2. The internal adopts assembled structure which has improved the accuracy of the equipment and it is easy to transport and install.

3. According to the characteristics of different fertilizers ,we have arranged the second granulation zone reasonably so as to improve the granulation effect .

4. Adopts assembled hoist board so as to exchange heat fully and lower the energy consumption .

5. Temperature induction monitor ,uniform vibration and airproof setting , which improve performance and productivity efficiently .

6. The assorted combustion furnace is a type of energy efficient and has the characteristics of smaller area , easy regulation and equipped with greenhouse

Compared with other manufacturer Rotary Kiln Nickel Ore Dryer advantage:

1.The drum dryer dry the material quickly.

2.Simple design, self-insulation, improve the heat efficiency to exceed 80%.

3.Structure delicate, stable operation.

4.good drying performance, coal consumption <8kg when drying 1 ton material.</p>

5.The fuel can be coal, oil, natural gas etc, dry mass, granule and powder material.

6.Reduce land area for 50% compared to single drum rotary dryer, so construction investment is saved 50%power consumption saved 60%.

7.Finished product moisture can be adjusted depends on requirement of client.

8.Lower outlet tempreture, loonger dust removal using life.

9.Drive by tug not gear.

10.Finished product tempreture lower than 60°C, packing can be done continuously.

Main Technical Parameters of Rotary Kiln Nickel Ore Dryer:

PLS NOTE: The technical parameter just for reference, we can according to customer specific required customized the model

FAQ

1) How is the quality of your products?

Our products are manufactured strictly according to national and international standard, and we take a test on every machine before delivery.

2) What guarantee do you provide?

If the quality is not consistent with the description as we said or promised before you place order, we promise you 100% refund.

3) How about price?

We have our own factory and can give you the lowest price, besides, we have a policy that " for saving time and absolutely honest business attitude, we quote as low as possible, discount can be given according to quantity"

Our Services:

Pre-sale services:

Act as a good advisor and assistant of clients; enable them to get rich and competitive

from the returns of their investment.

1) Select suitable equipment model.

2) Design and manufacture products according to clients' special requirements.

3) Train technical personnel for clients.

4) Professional suggestion for customer

Services during the sale:

Respect clients; devote ourselves to improving the total value of clients.

1)take photos(including raw material, semi-products, final products, and loading products)

1) Pre-check and accept products ahead of delivery.

2) Prepare all clearance documents, so that the customer clearance smoothly.

After-sale services:

Provide considerate services to minimize clients' worries.

1) Provide civil engineering drawings of the equipment.

2) Free training(including installation,maintenace) to every customer.

3) Install and debug the equipment, ensure the dryer running smoothly.

4) Examine the equipment regularly.

5) Take initiative to eliminate the troubles rapidly at site.

6) Distribute the guarantee fittings door-to-door.

7) Provide technical exchange and support.

8) Provide maintenance for big items.

9) The most preferential prices to provide customers the quick-wear parts.
