KU Band Maritime VSAT VS100
BIRDSAT's all new 100 cm ku vsat antenna is coming into the market now. Providing you the real-time information with excellent reliability performance and cost effective products as well as nautical satellite internet service, BIRDSAT is on the way to keep you connected and your safety.
Features of KU Band Terminal Maritime VSAT VS100
Increased signal receive & transmission capability
With improved signal receive and transmission module, BIRDSAT's new VS100 antenna can provide more stable real-time connectivity.
Higher wave transmittance, higher strength
The new GFRP material radome makes the wave transmittance and wind resistance increased significantly.
Easy installation, low cost
The antenna package can be installed directly on the patented shipborne bracket without dismounting the radome. All 3 cables combined into one cable and modem has also been integrated inside of the radome. BIRDSAT dedicates to improve the antenna performance but with lower cost.
Specification of KU Band Maritime VSAT VS100
Radome Dimension |
VSAT Weight |
132x138 cm (52x54.3 inch) |
124 kg / 273.4 lbs |
Reflector Diameter |
RX Frequency |
100 cm (39.4 inch) |
10.7~12.75 GHz Ku-band |
RX Gain |
TX Gain |
41.6 dBi @ 11.75 GHz (excl. radome) |
39.4 dBi @ 14.25 GHz (excl. radome) |
TX Frequency |
G/T |
13.75~14.5 GHz Ku-band |
18.5 dB/K |
As one of marine satellite internet providers, we can offer sorts of related products for sale, and the marine satellite internet cost is reasonable, if you have needs, please contact us.
There are many vsat satellite internet providers in China, but we are one of the best choices for you.
