KU-BAND AIRBORNE TERMINAL

KU Band Terminal

Cowave Airborne SATCOM terminal can be installed on various kinds of planes to provide remote control functions and communication traffic channels for the carrier.

This terminal has the characteristics of simple structure and easy installation. Video data transmission, remote sensing data backhaul, and other communication services are available by receiving control signals from the system control center. It can solve common problems such as remote control and broadband data transmission in UAV applications.

Specification of VAST KU Airborne Terminal

DIMENSION (DIAMETER X HEIGHT)

945mm × 260mm

• WEIGHT

41kg

• ANTENNA APERTURE

0.45m

• POLARIZATION MODE

Linear polarization

• RECEIVING G/T

12.1dBi@12.75GHz

• SENDING EIRP

48.4dBi@14.25GHz

• XPI

≥25dB

• TRACKING ACCURACY

0.2°RMS

• AZIMUTH ROTATION

360°

• PITCH ROTATION

0 ~ 90°

• HORIZONTAL ROLLING ROTATION

-30°~ 30°

• AZIMUTH PITCH SPEED/ ACCELERATION

60°/s200°/s²

• ALTITUDE

16800m

• WORKING FREQUENCY

Sending: 14GHz ~ 14.5GHz, Receiving: 12.25GHz ~ 12.75GHz

• BUC POWER

120W

• SUPPORT SERVICES

Control Data, Video Data, Remote Sensing Data

• DATA RATE

16Kbps ~ 2Mbps

• MODULATION

QPSK

• CODING

LDPC

• DATA INTERFACE

RJ45, Wi-Fi

• DATA SECURITY (OPTIONAL)

AES data encryption, RSA Key exchange

• OPERATING TEMPERATURE

-40℃ ~ +55℃

• EXTERNAL POWER SUPPLY 24V DC

24V DC

Features of Ku Band Modem Airborne Terminal

01

Simple structure and convenient installation— with antenna, modem, and other parts integrated inside of the radome, it is easy to install

02

General external interface— universal external interface, suitable for a variety of services for voice, video, and data transmission

03

Anti-rotor shielding ability, good communication effect— can prevent the signal intensity risk from the rotor shielding to keep the stable communication connection

Ku-Band Airborne Terminal Gallery

The antenna can dynamically adjust its azimuth and pitch to accurately aiming the satellite during high-speed flight.

Now the price of ku band vsat equipment is low, anything you need, please leave us a message.

As one of the VSAT China satellite service providers, our main products of the company include portable SATCOM terminals, vehicle SATCOM terminals, shipborne SATCOM terminals, airborne SATCOM terminals, satellite routers, SATCOM network management systems, etc., forming a complete set of SATCOM systems.

If you want to know more kinds of mobile satellite service terminal, please visit our website.
