Hunter-D shale shaker supplier
All listed shale shakers are designed by AIPU ourselves. Including Hunter-D series, Hunter-M series. All shaker screens can be fit on shakers by wedge blocks or hooks. According to clients' requirements it can be linear motion or balanced elliptical motion, even dual motion one. Please find following features on Aipu shale shaker:
1. All material is high quality national standard carbon steel from HBIS or Jinxi. Initially assured products quality
2. Stress reliving on shaker basket and other main parts. Getting longer service life
3. Sand blasting before painting the high anti-corrosive marine paint. Better appearance and better quality
4. Adopted famous vibration motors(Martin, Oli, or Ita-Vibras).High vibrating strength better filtration effect
5. Compact structure small foot print. Easy to handle and installation. Convenient to operate
6. A few spare parts. Easy to maintain and lower running cost
7. Competitive price with high cost-efficient
Hunter-D Shale shaker Parameter
Model |
Hunter-D3 |
Hunter-D4 |
Hunter-D3B |
Vibration Track |
Linear |
Linear |
BEM |
Motor Power |
1.72KWx2 |
1.94KWx2 |
|
Vibrating Strength |
>6 G |
>6.5 G |
|
Double Amplitude |
5~6mm |
||
Treating Capacity |
120m3/h 528GPM |
140m³/h 615GPM |
140m³/h 615GPM |
Deck Angle |
-1~5° |
||
Power System |
380V/50HZ, 460V/60HZ |
||
Shaker Screen |
720×1050×3 |
720×1050×4 |
720×1050×3 |
Decibels |
<85db |
||
Weight |
1600KG |
1800KG |
1950KG |
Dimension |
2800X1600X1500 |
3500X1600X1500 |
2800X1600X1500 |
Remark |
Dual tandem or triple tandem shakers available |
