Double Sided Kapton Tape
Double-sided kapton polyimide tape, also known as double sided kapton tape, is based on 0.025mm polyimide film as the substrate, coated with imported silicone adhesive on both sides, with a total thickness of 0.1mm, double-sided or single-sided composite PET fluorine release liner. This high temperature resistant double-sided polyimide tape has good insulation, wear resistance, acid and alkali resistance, can withstand high temperature 280 degrees/30 minutes, 260 degrees can be used for a long time.
Parameters Of Double Sided Kapton Tape
Color |
Amber |
Backing |
Polyimide film |
thickness (mm) |
0.1 |
Adhesion (N/25mm) |
9 |
Tensile Strength (kg/25mm) |
14 |
Elongation (%) |
65 |
Temperature Resistance (℃) |
280℃ 30mins |
Withstand Voltage (KV) |
4000 |
Length(mm) |
10 |
Release liner(mm) |
0.075 |
Features Of Double Sided Kapton Tape
Strong adhesion, good serviceability, high temperature and solvent resistance, no tin , no residual glue left on the covered surface after tearing
Excellent insulation, wear resistance, acid and alkali resistance, 280℃ can be used for a long time
This product has excellent electrical properties, low voltage, good mechanical properties, friction resistance, tear resistance
A variety of specifications 5mm-500mm can be customized according to the requirements of each body
If you want to buy a high quality china high temperature masking tape, please contact us.
