Customized Sapphire blue Changjiang750cc Sidecar Tricycle
ITEM DESCRIPTION
1. Model Number: CJ750B
2. Material: iron, painted
3. Style: Classic military theme
4. Color: Sapphire blue
5. Engine: 750cc
6. Customization: is welcomed, we can do patterns on car body
7. Available Colors: any color
8. MOQ: 1 piece
9. Optional capacity: we can change the engine with 250cc, 300cc, 350cc, 750cc
10. Optional Equipment: two ammo cans, blackout lamp, gun rack, disc brack, BWM-R71 fuel tank, spare fuel tank, small tool box
REMARK
1. Because of different monitors and brightness, there may exists tiny color difference.
2. Items will be insured from damage during transport from our factory to the destination port. If you want the items shipped to your house, please contact us.
3. We are not responsible for any duties, taxes, or additional charges that may be charged by Customs for any International deliveries.
4. There are two optional packing methods.
1) Wooden box packing
Cargo is Packed with un-fumigated wooden box.
SHIPMENT
We ship the item by sea generally, if you have other ideas please cantact us.Customized items will be shipped in 15 work days on payment received. Please make sure the shipping address is correct. We are not responsible for wrong address.
For detailed shipping costs, please contact us.
Packing Detail
Rolled with a plastic paper into a cube steel shelf, and then covered by steel net.
Weight after packing: 460kg/piece
Size after packing: 2200×1600 × 1270mm3
Price terms
This car can't send express, need normal customs clearance, The costs(5422US$) include: steel tower packing, into the storage fee, customs clearance fee, 17% of the value-added tax(922).Sea freight are different from places , please contact us according to the country to modify the freight.
Packing Detail
Rolled with a plastic paper into a cube steel shelf, and then covered by steel net.
Weight after packing: 420kg/piece
Size after packing: 2400×1800 × 1270mm3
6pcs in 20" container
14pcs in 40" container
Technical Data
|
Model category |
Antique750B—A1 |
Antique 750B—A |
||
|
1 performance criterion |
Brake distance |
≤8m |
||
|
Top speed |
≥85KM/H |
|||
|
MIN steady speed |
≤25KM/H |
|||
|
gradeability |
≥15° |
|||
|
Economic speed |
50KmH |
|||
|
Economic speed fuel consumption |
≤4.6L/100Km |
|
||
|
2 Vehicle size and quality parameters |
Dimensions |
2230 ×1590 ×1000mm |
||
|
fore-and-aft wheelbase |
1492mm |
|||
|
Fore-and-side wheelbase |
1147mm |
|||
|
tread |
1175mm |
|||
|
Ground clearance |
140mm |
|
||
|
Turn round-diameter |
6065mm,4380mm |
|||
|
Dry weight |
320kg |
|||
|
Max payload |
220kg |
|||
|
3 The engine and the ignition system |
Type Model |
series of F2P78FMF1 |
series of D2P78FM |
|
|
type |
Four-stroke double-cylinder air-cooled and Horizontally-opposed |
|
||
|
Total displacement |
746ml |
|
||
|
Cylinder diameter*stroke |
78×78mm |
|
||
|
Compression ratio |
7: 1 |
6: 1 |
|
|
|
Min no-loading stabilized speed(idling) |
750±75r/min |
|
||
|
Direction of power and appropriate speeds |
17.7KW(24HP)/4000±300r/min |
14KW(19HP)/3600±300r/min |
|
|
|
Max power and its corresponding speed |
22KW(30HP)/5000±300r/min 17.7KW(24HP)/4000±300r/min |
|
||
|
Max torque and its corresponding rotary |
49N(5kgf·m)/3800±300r/min 39.2N·M(4gf·m)/3000±300r/min |
|
||
|
Gear position No. 1 Gear position |
16.63: 1 |
|
||
|
No. 2 Gear position |
10.55: 1 |
|
||
|
No. 3 Gear position |
7.85: 1 |
|
||
|
No. 4 Gear position |
6.01: 1 |
|
||
|
Rear drive ratio |
4.62: 1 |
|
||
|
Starting mode |
Kick & electric |
|
||
|
Way of ignition |
battery ignition system with contact |
|
||
|
Spark plug type |
T4135J or T4114J |
|
||
|
Spark plug clearence |
0.6~0.7mm |
|
||
|
Valve clearence |
Air intake,exhaust: 0.1mm |
|||
|
4 Fule and lubrication |
Capacity of gasoline |
26L |
||
|
Fuel trademark |
70#or90#gasoline(SH0112—92) |
|||
|
Oil capacity of crankcase |
2L |
|
||
|
Transmission case engineoilcapacity |
0.8L |
|||
|
Oil capacity of rear drive |
0.175L |
|||
|
Lubricator oil |
||||
|
>0°C,HQ1.0GB485: <0°C,HQ6GB485</p> |
|
|||
|
5 Drive system |
Cluth |
Mechanically controlled double-disc. Dry friction |
||
|
Tyre size (inch) |
3.75—19 |
|||
|
Tyre pressure(kpa) |
Front wheel 250±20kpa,rear wheel335±kpa,side wheel350±20kpa |
|||
|
Brake pattern |
The front brake: drum handbraking rear brake: drum footbraking |
|
||
|
6 Electrical system |
Rated voltage |
12V |
|
|
|
Storage battery |
6QA36 |
|
||
|
Alternator |
MJF—280B |
|
||
|
silicon rectifier |
GZL—22 |
|
||
|
regulator |
JFT—149 |
|
||
|
starting dynamo |
MZQ—07A |
|
||
|
starting relay |
JN3—12 |
|
||
|
Headlamp |
12V60/55W |
|
||
|
Cornering lamp |
12V20W |
|
||
|
taillight |
12V20/8W |
|
||
|
Electric hom |
12V,≤3A |
|
||
Product Catalogue
1)125CC, 200cc, 250cc,300cc, 350cc, 600cc, 750cc sidecars
2) electric sidecars/cars/KAINDUDU sidecars
3) 250cc engine, 650CC ,750cc engines.
4) sidecar/motorcycle accessories and parts.
