Cone-shaped Permanent Magnets

The special circular magnet with the axial magnetization of different sizes at both ends is cone-shaped magnet. The large surface is usually described as the base of the cone-shaped permanent magnet. Compared with the base, the top surface generates a concentrated and stronger magnetic field. Our cone-shaped magnets for sale are made of neodymium-iron-boron alloy, which has a strong magnetic force. Some dimensions are carried out as standard cone magnets of neodymium for worldwide magnet distributors.

Neodymium Cone Magnets for Sale

Cone Magnets 10x5x4mm

Neodymium Rare Earth Cone Magnets Ø10/5x4mm-N45 Nickel Plated

Cone Shaped Rare Earth Neodymium Magnets Ø10/5x4mm - Force 1.2 kg

Cone Magnets 15x8x6mm

Ø15/8x6mm Rare Earth Neodymium Cone Magnets N42- Nickel Plated

Cone Shaped Rare Earth Neodymium Magnets Ø15/8x6mm-Force 3.1kg

Cone Magnets 20x10x8mm

Cone shaped Rare Earth Cone Magnets Ø20/10x8mm N38- Nickel Coating

Strong Cone Magnets Ø20/10x8mm-Rare earth Neodymium- Pull 4.9 kg

Cone Magnets 25x13x10mm

Neodymium Rare Earth Cone Magnets Ø25/13x10mm Nickel Plated

Strong Cone Shaped Rare Earth Neodymium Magnets Force 8.6kg

Rare earth Neodymium Cone Magnets

Cone neodymium magnets have a large face (often referred to as the base) and a small face (often referred to as the top). They usually magnetized axially. The magnetic force of neodymium cone magnets is very strong. The conical design helps to remove powerful magnets from any surface. When using the small magnetizing surface, cone shaped magnets are ideal magnetic pins, they are very suitable for whiteboards, magnetic boards, etc. They can firmly fix multiple A4 papers and easily remove them. If the base is attached to a metal surface, it is difficult to remove. The neodymium rare earth cone magnets are fragile. If the bottom is hit strongly, the cone-shaped magnets will be broken.
