Air-blowing Central Loose Tube Micro Fiber Cable（GCYFXTY）
Quantité : 2500km/wee Prix : <200 USD
Description:
There are two common structures for Air-blowing central Loose tube Micro fiber cable. One is a air-blowing smooth micro-cable and the other is a air-blowing micro-grooved micro-cable. The structure of Air-blowing micro tube fiber optic cable is completely different from that of the conventional fiber cables.
The outer sheath is made of high-density polyethylene material. Loose tube and non-metallic reinforcements have tensile, side pressure and moisture resistance. The tube filled fiber paste has the properties of sealing waterproof, anti-stress buffering, and protecting the light solder. The fiber bundle uses a full chromatographic identification fiber, and each of the 12 fibers is bundled with colored tying yarn. The optical properties, geometrical characteristics and mechanical properties of the optical fiber are the same as those of the conventional optical cable currently used. Specifically, the user selects different types of optical fibers such as G.652 or G.655 according to the requirements of the transmission line.
Application:
FTTx
LAN communication FTTx
Suitable for air-blowing installation
Product Parameter
|
No. of cable
|
/ |
2~12 |
12~24 |
|
|
Fiber type
|
/ |
G.657 |
||
|
Loose Tube
|
Material
|
mm |
PBT |
|
|
Diameter (±0.05mm)
|
1.6 |
2.4 |
||
|
Thickness (±0.03mm)
|
0.3 |
0.4 |
||
|
MAX.NO./per
|
2-12 |
14-24 |
||
|
Non metallic strength
|
Material
|
/ |
Aramid yarn
|
|
|
Outer Sheath
|
Material
|
mm |
HDPE |
|
|
Thickness
|
0.5 （nominal） 0.40 (min.)
|
|||
|
Colour
|
Black.
|
|||
|
Cable Diameter(±0.2mm)
|
mm |
2.5 |
3.5 |
|
|
Cable Wetght(±10.0kg/km)
|
kg / km |
3.5 |
4.5 |
|
|
Attenuation coefficient
|
1310nm
|
dB/km |
≤0.35 |
|
|
1550nm
|
≤0.21 |
|||
|
MAX. Tensile Strength
|
N |
120 |
150 |
|
|
MAX.Crush Resistance
|
N/ 100mm |
1000 |
||
|
Min. bending radius
|
Without Tension
|
mm |
10.0 × Cable-φ
|
|
|
Under Maximum Tension
|
20.0 × Cable-φ
|
|||
|
Temperature range (°C)
|
Installation
|
°C |
-10°C+40°C |
|
|
Transport&Storage
|
-40°C+60°C |
|||
|
Operation
|
-30°C+50°C |
|||
