Office Container
|
Size |
5950mm(L)*2250mm (W)*2690 mm(H)(external size) 5700mm(L)*2020mm(W)*2390mm(H)(internal size)Or 6050mm(L)*2438mm (W)*2590 mm(H)(external size) 5875mm(L)*2255mm(W)*2325mm(H)(internal size) |
Foundation |
Simple concrete foundation or solid floor slab required |
Base |
Profile steel; Plywood/fiber cement panels+ vinyl/PVC surface flooring. |
Steel frame |
Frame structure: cold formed profile steel, 4mm thickness; Corrosion Protection: Polishing, derusting, sand blasting; Finishing coat: alkyd honed painting; Connected by bolts or screws. |
Wall and roof boards |
Sandwich panels, GI sheet, decoration panels, panels thickness will be 50mm, 75mm, or 100mm PU, EPS, Rockwool or others. |
Roof |
Sandwich panels, GI sheet, asphalt shingle. Panels thickness will be 50mm, 75mm, or 100mm PU, EPS, Rockwool or others. |
Outside doors |
Steel security doors or aluminium doors; The dimensions of doors are 800 X 1950 mm. |
Interior doors |
Wood, aluminum or sandwich panels doors. |
Windows |
Main material is PVC double glass sliding, aluminium, gypsum windows and etc;The window dimensions are 900/1100mm and they may vary upon request. |
Exterior decoration |
PVC ex-hanging panels, metal carved boards or MDF decorative boards and etc. |
Electricity |
The electrical installation is hidden, laid in plaster depth. The cables are HES brand, for the fuses Siemens automates are used. For the sockets cables of 2 X 2.5, lighting 2 X 1.5 are used. The switches and sockets are VIKO brand. In each room, there is one switch and two sockets. Split air conditioning installation will be made at the container. |
Sanitary |
The installations are made plaster depth. Clean water piping are FIRAT brand. The tea furnace is chrome steel kitchen sink. Wash basins and lavatory bowls are DOGVIT brand. |
Technical parameters |
|
Standard roof load |
0.5KN/m2(can reinforce the structure as required) |
wind speed |
Wind speed designing 210km/h (Chinese standard) |
seismic resistance |
magnitudes 8 |
Temperature suitable |
temperature.-50°C~+50°C |
Fireproof |
Grade 3 |
component long beam |
3mm galvanized steel material |
Weight |
1950kgs |
short beam |
2.5mm galvanized steel sheet |
column on the corner |
3mm galvanized steel raw material |
secondary beam |
Z-shaped galvanized steel |
Floor panel |
18mm plywood panel+12mm laminated floor or 20mm cement-fiber +2mm vinyl flooring |
Forklift |
Two forklift on the base to move from one site to another |
External power |
If possible, we will add one or two external power holes on the roof panel. |
Item |
Material and Specification |
Size |
|
Dimensions |
External (L*W*H) |
5950mm*3000mm*2800mm |
Standard |
Internal(L*W*H) |
5800mm*2800mm*2500mm |
Standard |
|
Roof structure |
roof beam |
ss400-hdg hot dip galvanized profiled parts |
5630mm*160*2.3mm |
roof rail |
ss401-hdg hot dip galvanized profiled parts |
2680mm*160*2.3mm |
|
roof square tube |
50*50*1.8 hot dip galvanized |
|
|
roof corner |
45steel punching tee corner |
5mm |
|
roof frame square pipe |
40*80*1.2 galvanized |
|
|
roof frame square pipe |
40*60*1.0 galvanized |
|
|
roof tile |
980type contianer special tile |
0.45mm |
|
ceiling tile |
981type contianer special tile |
0.25mm |
|
pressure plate slot |
1.2mm galvanized bending |
|
|
Thermal insulartion material |
glass wool |
|
|
Base structure |
base beam |
ss400-hdg hot dip galvanized |
5630mm*160*2.3mm |
base rail |
ss400-hdg hot dip galvanized |
2680mm*160*2.3mm |
|
base corner |
45# steel stamping tee corner |
4.7mm |
|
base purlin |
Hot dip galvanized square pipe 1.2mm |
40*80*2990 |
|
base purlin |
Hot dip galvanized square pipe 1.2mm |
80*80*2990 |
|
floor |
grade A fireproof glass magnesiu board |
16mm |
|
Corner column |
corner column |
2.3mm formed section |
2480mm*160mm |
Painting |
Plastic spraying + paint baking |
outdoor plastic powder |
according to customer color requirements |
Connector |
bracket connecting screw |
M12*30 strength grade 8.8 |
|
frame screw |
M12*25 galvanized carrage screw |
|
|
Wind resistant connector of frame body |
M20 |
|
|
chassic screw |
long rod galvanized screw |
M10*100 M10*60 |
|
wall panel |
wallboard |
doubl-sided rock wool sandwich board |
steel plate thickness: 0.3mm |
door and window |
door |
plastic-sprayed steel handle |
with frame |
window |
aliminium alloy security window |
Single glass aluminum profile window |
|
decorative strip |
roof corner line |
3*3 aluminium alloy |
|
coloumn corner line |
plastic spraying inner arc aluminum profile |
width:75mm |
|
|
|||
optional material: high-grrade decoration material |
Item |
Material |
Remarks |
PVC inner corner wall skirt |
PVC |
|
|
Flat iron sheet concealed ceiling |
0.326 color steel |
|
|
PVC engineering vinyl roll sheet |
Refractory plastic |
many colors is available |
|
High grade hollow glass windows |
plastic steel |
Hollow tempered glass |
|
glass curtain |
aluminum alloy |
customization |
|
electric equipment |
Item |
Brand |
|
The electric box |
famous brand |
|
|
Double row leak protector |
|
||
LED energy-saving lamp tube |
|
||
An open |
|
||
Air conditioning socket 16A |
|
||
USB socket * 4 |
|
||
Galvanized JDG pipe + connector |
|
||
Single conductor |
2.5Square MM, National Standard |
||
Single conductor |
2.5 Square MM National Standard |
||
Single conductor |
1.5Square MM National Standard |
||
Memo |
Note: Container toilets are made by aluminum-plastic board floor, stainless steel sink drainage system, all wood-plastic board baffle holes. Exhaust fans, blinds, etc. Shower container aluminum plastic board floor, PVC pipe shower head. |
||
Zhongtai House is a professional prefabricated china steel frame building manufacturer, the flat pack container house is our main product, and we can provide a daily production capacity of 200 sets, fully meeting your high-end, middle, and low-end product needs. Our house type includes container house (Flat pack container, Detachable container, Folding container), Prefab house, H beam Steel structure, and cold-formed light steel structure villa. With the modern facility located in the Handan plant, Zhongtai has the capability to manufacture 6,000 Units of container houses and 70000 sqm ( building area )prefab houses per month.
