240W 36V 6A Battery Charger
240W 36V 6A Battery Charger
Typical output: 36V 6A battery charger
Fully auto 4 stages charging process by MCU controller
4 LED indicate the battery capacity from 25%~100%
Worldwide AC input 100V-240V
Charging stage: Small current pr-charge; constant current charging; Constant voltage charging
The Specifications Of 240W 36V 6A Battery Charger
|
Charger Model |
AC Input Voltage |
Battery Voltage |
Max Voltage(V) |
Max Current (A) |
|
|
AP-PN240CH01460160 |
100-240 |
12 |
14.6 |
16 |
|
|
AP-PN240CH02920080 |
100-240 |
24 |
29.2 |
8 |
|
|
AP-PN240CH04200060 |
100-240 |
36 |
42 |
6 |
|
|
AP-PN240CH05460040 |
100-240 |
48 |
54.6 |
4 |
|
|
AP-PN240CH01200160 |
100-240 |
12 |
14.7 |
16 |
|
|
AP-PN240CH02400080 |
100-240 |
24 |
29.4 |
8 |
|
|
AP-PN240CH03600060 |
100-240 |
36 |
44.1 |
6 |
|
|
AP-PN240CH04800040 |
100-240 |
48 |
58.8 |
4 |
|
|
INPUT |
AC Input Voltage Range |
100V ~ 240V |
|||
|
AC Input Frequency |
45~65HZ |
||||
|
AC Power Factor Correction |
≥0.98 |
||||
|
OUTPUT |
Output Voltage Range |
12~60V |
|||
|
Output Power Range |
16A（Max） |
||||
|
VIBRATION |
10～50HZ 2G 10 minutes，X，Y，Z /60 minutes |
||||
|
DIMENSIONS(mm) |
(L) 203х (W) 81х (H) 47.5 |
||||
|
Protections |
Over current protection ,Over Voltage Protection ,Short- circuit Protection Reverse Connection Protection ,Battery open-circuit protection |
||||
|
CERTIFICATIONS |
CE ROHS |
||||
|
PACKING DETAILS |
1.2kg/pcs 1pcs/Carton Carton size: 203*81*47.5mm |
||||
As one of the most professional 24v 5a battery charger factories, we provide 180w power adapter, US Wall Power Adapter, industrial power adapter and etc. For more information, please feel free to contact us!
