2 inch Automatic Disc Filter
2-inch Automatic Disc Filter Introduction
Rosun 2 inch disc filter features deep, self-locking filtration ensuring stable filtration efficiency. It has the ability to capture fibrous and soft impurities efficiently.
Automatic self cleaning disc filter introduces Israel's advanced recoil unit, which only about 7-20 seconds to complete, in general, backwash water consumption is less than 0.5% of the filtered water, for viscous impurities, fibrous impurities can also achieve high-efficiency recoil. External recoil mode is provided and the required filter liquid can be reduced to zero.
The Advantage of Disc Filter
Stable filtration efficiency
High-efficiency backwash. when backwash it can save energy and water
Automatic control, continuous filtration
save space
Reliable operation, long life, the cost of system operation is low.
Specification of 2 inch Automatic Disc Filter
|
Filter unit |
2 inch |
|
Number of filter elements |
1 |
|
Filtration accuracy |
20um-400um |
|
Backwash pressure |
greater than 2.8Bar |
|
Maximum working pressure |
10Bar |
|
Filtration area |
880cm3 |
|
Backwash flow rate |
8.11m3/h x 1 |
|
Maximum flow |
20t/h |
|
Backwash time |
10-20 seconds |
|
External material |
Reinforced Nylon, PP |
|
Inlet and outlet interface |
2-inch NPT, clamp |
|
Dimensions |
490 x 290 x200 |
|
Weight |
6kg |
There are many disinfectant suppliers, but we are one of the best choices for you.
