12-24 fibers Outdoor FTTH Drop Cable Steel Wire&FRP
Quantité : 2500km/wee Prix : <200 USD
Description:
It is a central tube of FTTH outdoor drop cable(GJYXFCH) also called self-supporting butterfly drop optical cable. Compared with common self-supporting drop optical cable.
The fiber cores for this cable structure can be 12-24 cores. It is for outdoor FTTH applications.
Features of our steel wire FTTH frop cable:
Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property
Two parallel strength members ensure good performance of crush resistance to protect the fiber
Simple structure, light weight and high practicability
Novel flute design, easily strip and splice, simplify the installation and maintenance
Low smoke, zero halogen and flame retardant sheath
Simple structure, light weight and high practicability
Application:
Used in indoor cabling, especially used for FTTH
Used as access building cable
Product Parameter
|
No. of cable |
12-24 |
|||
|
Fiber Model |
G.657A1 |
|||
|
Steel wire |
Diameter（±0.03）mm |
1.0 |
||
|
NO. |
1 |
|||
|
FRP |
Diameter（±0.03）mm |
0.5 |
||
|
NO. |
2 |
|||
|
Loose tube |
Material |
PBT |
||
|
Color |
Natural |
|||
|
Diameter（±0.06）mm |
2.0 |
|||
|
Thickness（±0.03）mm |
0.35 |
|||
|
The Max.Core NO./Tube |
twenty four |
|||
|
Outer Sheath |
Material |
LSZH |
||
|
Colour |
Black |
|||
|
Cable Diameter（±0.2）mm |
4.0x8.5 |
|||
|
Cable Weight（±2）kg/km |
45 |
|||
|
Attenuation |
1310nm |
dB/km |
0.4 |
|
|
1550nm |
0.3 |
|||
|
Allowable Tensile Strength |
Short Term |
N |
600 |
|
|
Long Term |
300 |
|||
|
Allowable Crush Resistance |
Short Term |
N/100mm |
2200 |
|
|
Long Term |
1000 |
|||
|
Min. bending radius |
Without Tension |
15.0 × Cable-φ |
||
|
Under Maximum Tension |
30.0 × Cable-φ |
|||
|
Temperature range (°C) |
Installation |
-20~+60 |
||
|
Transport&Storage |
-40~+70 |
|||
|
Operation |
-40~+70 |
|||
