10.1 Inch 1280x800 LVDS Interface IPS TFT LCD Screen
Kingtech 10.1inch 1280x800 landscape IPS All/free/wide viewing angle TFT LCD display is one of our main products.
The 10.1inch LVDS TFT LCD module has capacitive touch and support I2C and USB interfaces. The 10.1inch TFT screen has HDMI Board, it can be connected with Raspberry Pi to operate.
Kingtech Diaplay, as a LCD manufacturer, has achieved great progresses in producing custom LCD panel. We promoise that we will provide the customers with qualified standard dispalys and satisfying one-stop services. Any requests will be welcomed.
Features of 10.1 Inch 1280x800 LVDS Display Interface IPS TFT LCD Screen
1280x800 resolution /High definition resolution
All / Free / Wide viewing angle
IPS type
LVDS interface
Landscape display
Support capacitive touch 12C and USB interfaces
Support HDMI Board
Specification of 10.1 Inch 1280x800 LVDS Interface IPS TFT LCD Screen
|
Item |
10.1inch 1280x800 TFT module display |
|
Model No |
PV101010LZR40F |
|
Resolution |
1280*800 |
|
Outline Dimension |
229.46(W)*149.10(H)*2.8(T) |
|
Active Area(mm) |
216.96(W)*135.60(H) |
|
Board |
HDMI board |
|
Touchscreen |
I2C / USB capacitive touchscreen |
|
Viewing Angle |
All |
|
Display Mode |
Transmission / Normally Black |
|
Operating Temperature |
-10℃~70℃ -30℃~80℃ for option |
|
Storage Temperature |
-20℃~70℃ -30℃~85℃ for option |
|
Brightness |
350nits - 1000nits |
|
Interface |
LVDS Interface |
Application of 10.1 Inch 1280x800 LVDS Interface IPS TFT LCD Screen
The 10.1inch 1280x800 LVDS IPS TFT LCD display can be used for medical devices, handheld equipment, industrial control, smart home, logistics device, and E-Bike.
Kingtech is one of the leading lcd panel suppliers, we provide tft lcd 3.5, lcd module,lvds lcd panel, lvds lcd, crystal display and etc. Want to know more? Please contact us.
